The CTS2030 from GIS Laser is a patented, high precision Computer to Screen (CTS) direct exposure machine designed for screen imaging. It utilizes DMD digital imaging technology and a 405nm laser module. It creates crisp, high-resolution images directly on screens for various graphics applications like textile printing, packaging, PCB manufacturing, and 3C printing. With a comprehensive system including a precision optical lens, stable motion platform, and robust software, our CTS2030 sets the standard for precise and reliable screen imaging.
|
Specification / Model |
CTS2030 |
|
Max screen size |
2000x3000mm(78.74x118.11") |
|
Min screen size |
700x700mm(27.56x27.56") |
|
Max exposure size |
1900x2900mm(74.8x114.17") |
|
Screen frame thickness |
25-50mm(bespoke service is available) |
|
Imaging System |
DMD DLP Technology |
|
Emulsion thickness (EOM) |
Solvent resistant emulsion 3um-150um, water resistant emulsion 3um-500um |
|
Exposure time |
120-240s/㎡, #350 yellow mesh |
|
Resolution |
1270dpi/2540dpi/12700dip(vector)(optional) |
|
Raster |
Up to 133LPI |
|
Focus system |
Dynamic focusing |
|
File format |
1 bit Tiff, Gerber, PDF vector etc. |
|
Laser type |
UV laser, wavelength 405+5nm |
|
Laser power |
20W/25W/30W(optional) |
|
Equipment size |
4350x3000x1430mm(171.26x118.11x56.3") |
|
Equipment net weight |
3800Kg |
|
Conditions |
Yellow light room with cleanliness Class 10000,temperature 22+2°c, 40-70% relative humidity (no condensation) |
| Power |
Single phase 110V/220V,50/60Hz,4kW, Compressor air 0.5MPa |
*Specifications subject to change without notice
